2025 Kawasaki TERYX KRX 1000 eS

Standard

• Starting - Electric
• Ignition - Digital
• Lubrication - Forced lubrication, wet sump
• Final Drive - 2WD/4WD, shaft
• Transmission - Dual-range (high/low) CVT with centrifugal clutch and reverse
• Engine - 999cc, liquid-cooled, 4-stroke, DOHC 4-valve-per-cylinder parallel twin
• Bore x Stroke - 92.0 x 75.1 mm
• Compression Ratio - 11.5:1
• Fuel System - Fuel injection: ø50 mm x 2

Standard

• Warranty - 6 months
• Kawasaki Protection Plus - 12 / 24 / 36 / 48 months
• Lighting - 2x LED headlights
• Wheelbase - 2,510 mm (98.8 in)
• Fuel Capacity - 40 litres
• Tread (F/R) - 1,505 mm (59.3 in) / 1,510 mm (59.4 in)
• Turning Radius - 6.2 m (20.3 ft)
• Cargo Bed Dimensions (LxWxH): 370 x 840 x 230 mm (14.6 x 33.1 x 9.1 in)
• Seating Capacity - 2
• Vehicle Load Capacity - 354 kg (780 lb)
• Seat Height - 800 mm (31.5 in)
• Dimensions (L x W x H) - 3,355 x 1,730 x 1,955 mm (132.1 x 68.1 x 77.0 in)
• Road Clearance - 355/365 mm (standard/max preload) (14.0/14.4 in (standard/max preload))
• Cargo Bed Capacity: 159 kg (351 lb)
• Instrumentation - 7” high-grade full-colour TFT LCD screen with speedometer, tachometer, fuel gauge, gear indicator (L, H, N, R), Driving Mode (2WD/4WD/4WD+Diff Lock), Power Mode (Full/Low), Suspension Mode (Soft/Normal/Firm), clock, CVT temperature; selectable display that includes: digital tachometer, odometer, dual trip meters, total time, trip time, average speed, water temperature, battery voltage; Economical Riding Indicator, maintenance reminder (2 driver-selectable reminders), and a range of indicators and warning lamps
• Curb Mass - 879 kg (1,938 lb)

Standard

• Engine Management Technology - Economical Riding Indicator, Power modes
• Chassis Management Technology - ERGO-FIT, KECS

Standard

• Frame - Ladder type, tubular steel
• Steering - Rack and pinion with Electric Power Steering
• Rake / Trail - 10.0° / 65 mm
• Steering Angle (L/R) - 34° (IN) / 29° (OUT), 34° (IN) / 29° (OUT)
• Front Tire - MAXXIS Carnivore 31 x 10.00R15 8PR, with bead-lock wheels
• Rear Tire - MAXXIS Carnivore 31 x 10.00R15 8PR, with bead-lock wheels
• Front Brake - Dual ø258 mm discs with twin-piston (ø32 mm x2) calipers
• Rear Brake - Dual ø258 mm discs with single-piston (ø38 mm x1) calipers
• Parking Brake - Auto-adjust mechanical disc
• Rear Suspension / Wheel Travel - 4-Link Trailing Arm rear suspension, FOX 2.5 Live Valve Internal Bypass shocks with piggyback reservoir, KECS-controlled compression damping, and manually-adjustable spring preload / 536 mm (21.1 in)
• Front Suspension / Wheel Travel - Double wishbone, FOX 2.5 Live Valve Internal Bypass shocks with piggyback reservoir, KECS-controlled compression damping, and manually-adjustable spring preload / 472 mm (18.6 in)
