2025 Kawasaki MULE SX 4x4 XC LE

Standard

• Starting - Electric
• Lubrication - Forced lubrication, wet sump
• Engine - 401cc, air-cooled, 4-stroke, OHV single
• Bore x Stroke - 82.0 x 76.0 mm
• Compression Ratio - 8.6:1
• Fuel System - Fuel injection: ø23 mm x 1
• Ignition - Battery & coil
• Transmission - 2-speed automatic, forward/reverse
• Final Drive - Gear, selectable 2WD/4WD, dual-mode differential

Standard

• Kawasaki Protection Plus - 12 / 24 / 36 / 48 months
• Warranty - 36 months
• Dimensions (L x W x H) - 2,710 x 1,335 x 1,905 mm (106.7 x 52.6 x 75.0 in)
• Wheelbase - 1,780 mm (70.1 in)
• Road Clearance - 190 mm (7.5 in)
• Seat Height - 840 mm (33.1 in)
• Curb Mass - 498 kg (1,098 lb)
• Fuel Capacity - 16 litres
• Tread (L/R) - 1,080 mm (42.5 in) / 1,050 mm (41.3 in)
• Turning Radius - 3.6 m (11.8 ft)
• Cargo Bed Dimensions (LxWxH) - 905 x 1,040 x 245 mm (35.6 x 40.9 x 9.6 in)
• Cargo Bed Capacity - 181 kg (400 lb)
• Seating Capacity - 2
• Vehicle Load Capacity - 401 kg (884 lb)
• Towing Capacity - 500 kg (1,100 lb)
• Lighting - 4x LED headlights
• Instrumentation - Digital fuel gauge, hour meter

Standard

• Frame - Ladder type, tubular steel
• Front Suspension / Wheel Travel - Independent, MacPherson strut / 78 mm (3.1 in)
• Rear Suspension / Wheel Travel - Unit swing axle / 79 mm (3.1 in)
• Steering - Rack and pinion
• Rake / Trail - 9° / 50 mm
• Steering Angle (L/R) - 41° (IN) / 35° (OUT), 41° (IN) / 35° (OUT)
• Front Tire - 26 x 9.00-12
• Rear Tire - 26 x 9.00-12
• Front Brake - Dual hydraulic drums
• Rear Brake - Dual hydraulic drums
• Parking Brake - Mechanical, on rear wheels
